Horizontal Stainless Steel Multi-Station Fully Automatic Premade Bag Packaging Machine
| Place of Origin | Guangdong，China |
|---|---|
| Brand Name | ZCHONE PACK |
| Certification | ISO，CE |
| Model Number | ZC-S210 |
| Minimum Order Quantity | 1set |
| Price | $12,900~$16,900 |
| Packaging Details | Standard export wooden case packaging |
| Delivery Time | 15 |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 1/sets/15day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Horizontal Granule Packing Machine | Voltage | 220V/380V |
|---|---|---|---|
| Automatic Grade | Automatic | Condition | New |
| Application | Food,Chemical,Medical,Commodity,Machinery & Hardware | Packaging Type | Bags, Pouch，pouches |
| Highlight | Fully Automatic Premade Bag Packaging Machine,Horizontal Premade Bag Packaging Machine,Multi Station Premade Bag Packaging Machine |
||
You can tick the products you need and communicate with us in the message board.
| Packing Machine Type | |
|---|---|
| Granule Packing Machine | |
| Liquid Packing Machine | |
| Powder Packing Machine | |
| Stand-Up Pouch Packing Machine | |
| Vertical Packing Machine | |
| Horizontal Packing Machine | |
| Tea Bag Machine | |
| Coffee Bean Packing Machine | |
| Horizontal Packing Machine |
Product Description
Horizontal Stainless Seel Multi-station Fully Automatic Premade Bag Packaging Machine
Horizontal premade bag packaging machine is a machine and equipment used to automatically package products. It is suitable for various granular, powdery, block or flake products, such as food, chemicals, pharmaceuticals, etc.
The working principle of the horizontal premade bag packaging machine is as follows:
Raw material supply: Load the product into a feeding device, usually a vibrating feeder or screw feeder.
Bag pickup: The horizontal prefabricated bag packaging machine automatically takes out a bag from the bag pickup location and opens it.
Filling: After the bag is opened, the product enters the bag through the feeding device. Typically, the filling process controls the quantity and weight of the product.
Sealing: After filling is completed, the horizontal prefabricated bag packaging machine seals the bag. This is usually done by heat sealing or pressure sealing.
Advantages of horizontal preformed bag packaging machines include efficiency, precision and reliability. It can automatically complete the entire packaging process, improve production efficiency and reduce labor costs. In addition, it can adapt to bags of different sizes and shapes and has some flexibility.
It is important to note that the design and functionality of specific horizontal premade bag packaging machines may vary between different manufacturers and models. Therefore, it is best to refer to and follow the appropriate user manuals and guidelines when selecting and operating a machine.
Machine Specification:
| Model: | ZC-S210 | ZC-S110S | ZC-S140S | ZC-S160D | ZC-S160S | ZC-S160 | ZC-S210X | ZC-S260 | ZC-S320 |
| Packing speed: | 15-35bags/min | 20-80bags/min | 30-90bags/min | 20-350bags/min | 40-70bags/min | 10-50bags/min | 10-45bags/min (depending on product weight) | 20-40bags/min | 20-35bags/min |
| Total power: | 2.5KW | 5KW (single host) | 5KW (single host) | 3.5KW (single host power, additional system power) | 5KW(single host) | 2.0KW(single host) | 2.5KW(single host) | 4.5KW(Single host power, supporting system power plus) | 4.5KW(Single host power, supporting system power plus) |
| Package dimensions | 80-160mm/130-320mm (W*L) (the adjustable range of M bag is 50mm) (the width of the packaging bag is slightly different according to the prefabricated bag) | 100-230mm/70-110mm(L*W) | 100-250mm/90-140mm(L*W) | Bag width: 65-85mm Bag length: 110-230mm (Special-shaped bag width specifications are customized according to customer specifications and cannot be adjusted) |
80-160*110-230 (bag width*bag length) | 100-210mm/110-300mm(W*L) | 140-260mm*160-380mm(W*L) | 160-320mm*160-380mm(W*L) | |
| Power supply: | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V | 380V |
| Total Weight: | 600KG | 1800KG | 2000KG | 800KG | 2000KG | 800KG | 900KG | 1200KG | 1500KG |
| Packaging capacity: | 20g-1000g (depending on the specific material) | 10g-200g | 10g-400g | 10g-100g | 10g-100g | 10g-500g (depending on the material) | 300g-2kg (depending on the material) | 200g-2kg(depending on the product) | 200g-3kg(depending on the product) |
| Air consumption: | 0.7m3/min | :0.7m3/min | 0.7m3/min | 0.7m3/min | 0.7m3/min | 0.7m3/min | 0.7m3/min | 0.7m3/min | 0.7m3/min |
| Bag Type: | M-type bag, M-type stand-up bag and other prefabricated bags | Various premade bags such as stand-up bags, four-side sealing bags, zipper bags, tote bags, paper bags, etc. | Various premade bags such as stand-up bags, four-side sealing bags, zipper bags, tote bags, paper bags, etc. | Various prefabricated bags such as stand-up bags, four-side sealing bags, paper bags, etc. | Various prefabricated bags such as stand-up bags, four-side sealing bags, tote bags, paper bags, etc. | Four-side sealing bag, three-side sealing bag, special-shaped bag, paper bag and other prefabricated bags | Various prefabricated bags such as stand-up bags, four-side sealing bags, zipper bags, tote bags, paper bags, etc | Various prefabricated bags such as stand-up bags, four-side sealing bags, zipper bags, tote bags, paper bags, etc. | Various prefabricated bags such as stand-up bags, four-side sealing bags, zipper bags, tote bags, paper bags, etc. |
| Dimensions: | 2900*1250*1350mm | 2760*1550*1350mm | |||||||
(We can provide you with exclusive packaging machine customization services according to your needs! Of course,If you need, we can also provide you with customized bag service)
